Plastmach's singe screw extruders are for extrusion of polyolefin (HDPE, HDPE PLB Ducting, PP, PP-R & LLDPE, LDPE) pipes. The extruders with screw diameters 16 mm to 400 mm are available for output range 100 kg/hr to 500 kg/hr.
This field proven design of energy efficient extruders comes with a combination of barrier screw and grooved feed bush results into optimum performance. Thus, resulting into a high-quality PE pipe which can be used for wide range of processing applications.
Features
- Energy-efficient extruder (one electrical unit delivering 3-4 kgs outputs)
- Provides excellent linearity of outputs
- Long screw designs with L/D ratio of 36:1 for excellent melt homogeneity
- 300 kg/hr pipe output with 45 mm extruder & 500 kg/hr with 60 mm extruders
- Versatile screw designed for PE & PP random co-polymer
- Direct coupled gearbox design ensures minimum transmission loss & compact layout
- Wear-resistant coating guarantees long screw life
- Grooved feed design extruder for highest efficiency
Unique Advantages
- Higher productivity compared to conventional design
- Uniform melt temperature
- Reduced power consumption (one electrical unit delivering up to 3 kgs to 4 kgs outputs)
- Wide range of processing applications due to longer L/D ratio
- Superior physical properties of end product
Applications
Extruder
| PM-SS Models for HDPE/PPR Pipe Extruders | |||||||
| Models | Unit | PM-SS-45/45 | PM-SS-45/56 | PM-SS-45/75 | PM-SS-45/90 | PM-SS-60/110 | PM-SS-60/132 |
| Screw Diameter | mm | 45 | 45 | 45 | 45 | 60 | 60 |
| L : D Ratio | – | 37:1 | 37:1 | 37:1 | 37:1 | 37:1 | 37:1 |
| Main Motor | kW | 45 | 56 | 75 | 90 | 110 | 132 |
| Max. Output (HDPE) | kg/hr | 140-160 | 180-190 | 220-240 | 300-330 | 380-400 | 500-550 |
| Max. Output (PPR) | kg/hr | 80-99 | 100-119 | 130-159 | 180-199 | 220-239 | 300-329 |
** (We offer single pipe, twin pipe & dual pipe extrusion system as well.)
Die Heads HDPE/PPR
Advantages
- Inner spiral pipe surfaces for optimum melt distribution
- Short purging time with least waste of material
- Uniform melt flow can be achieved
- Versatile screw & die designs enables PE & PPR process-ability only by changing the tools alone
- Possibility with high speed design up to 20 mtr/min for small sizes
| PM-PE Models for Die heads HDPE/PPR | |||||
| Models | Unit | PM-PE-50 | PM-PE-200 | PM-PE-250 | PM-PE-400 |
| Pipe Range | mm | 20-50 | 20-200 | 63-250 | 90-400 |
| Output Capacity PE | kg/hr | 200 | 350 | 400 | 500 |
| *Outputs on PPR pipes are approx. 35% of the PE outputs | |||||
| PM-PE Multilayer Pipe Die heads | ||
| Models | PM-PE-110-2L | PM-PE-110-3L |
| Pipe Range | 20-110 | 20-110 |
| Output Capacity | 300 kg/hr | 300 kg/hr |
| Number of layers | 2 Layer | 3 Layer |
| Multilayer PPR die heads are same with little difference in insert sets & reduced outputs up to 35% of PE | ||
Vacuum Sizing Tanks
Vacuum sizing is the most widely used arrangement for pipe production. We offer vacuum sizing tanks in stainless-steel highest-grade SS-304 for long service life & optimum results. Our vacuum sizing tanks design are suitable for various line requirements.
- Effective cooling design provided to ensure high production of pipes
- Self-cleaning spray nozzles are used
- Accurate vacuum control circuit, water level control circuit & automatic temperature control provided
- Axial movement provided for easy handling
- Manual slide rail arrangement for axial and transverse movement of the tank for ease of pipe center alignment
- Imported filters for inline cleaning
| PM-VST Models for Vaccum Sizing Tanks | ||||||
| Models | PM-VST-110 | PM-VST-200 | PM-VST-250 | PM-VST-315 | PM-VST-400 | |
| Pipe Size Range Single-Pipe | mm | 20-110 | 20-200 | 50-250 | 75-250 | 90-400 |
| Length Of Cooling | mm | 6000 | 6000 | 6000 | 6000 | 6000 |
| Dual Tanks* | with CD 400 mm | With CD 500 mm | – | – | – | |
| Dual Pipe Stand Models | Available | Available | – | – | – | |
| *Dual pipe strand tanks are offered for dual pipe extrusion | ||||||
Traction Unit
- Up to 2 track & 4 track and 6 track & 8 track to suit pipe diameters range
- Different line speeds available in wide range through servo and non-servo designs as per need
- Track adjustment by pneumatic pressure control
- Direct geared drive on individual tracks as standard
- Counter balance pressure to balance track weight for thin pipes
- Encoder for length measurement & feedback arrangement offered optionally
- Easy accessibility for maintenance of all components
- Dual twin-track traction units for dual pipe extrusion line
| PM-VST Models for Caterpiller Models | |||||||
| Models | PM-TTU 110 | PM-TTU-200 | PM-TTU-250 | PM-TTU-250/4 | PM-TTU 315/4 | PM-TTU 450/4 | |
| Pipe Range | mm | 16-110 | 20-200 | 50-250 | 63-250 | 63-315 | 75-450 |
| No. of Tracks | nos. | 2 | 2 | 2 | 4 | 4 | 4 |
| Max. Line Speed | mtrs./min. | 15 (or 20) | 10 (or 15) | 10 (or 15) | 7 (or 10) | 7 | 7 |
| Minimum Line speed | with std. drive | 1.2 (or 1.6) | 0.8 (or 1.2) | 0.8 (or 1.2) | 0.56 (or 0.8) | 0.56 | 0.56 |
| Minimum Line speed | mpm/with *servo drive option | 0.15 (or 0.2) | 0.1 (or 0.15) | 0.1 (or 0.15) | 0.07 (or 0.1) | 0.07 | 0.07 |
| Contact Length | mm | 800 | 1200 | 1600 | 1200 | 1200 | 1600 |
| Dual Pipe Strand Models | Available | Available | – | – | – | – | |
| *Servo option is available on additional charge | |||||||
Cutting Unit
Tube Cutting Unit (TCU)
- Carbide tipped cutting blades used in saw cutting units
- Chip-less cutting designs are available on request
- Pneumatically operated carriage movement
- Clamping force adjustable depending upon the wall-thickness of the pipe
- Swarf removal system available
- Trolley movement on linear motion bearings
- Special guillotine designed cutter for PPR pipes
- Dual cutter for dual pipe extrusion line
- Digital counter to measure length
- PLC based controls available optionally
| PMC Saw Cutter Models | |||||
| Models | Unit | PMC-110 | PMC-200 | PMC-250 | PMC-315 |
| Pipe Range | mm | 20-110 | 20-200 | 50-250 | 90-315 |
| Cutting Speed (Max.) | mtrs/min. | 18 | 10 | 10 | 6 |
| Clamping From | – | Top | Top | Top | Side/Top |
| Dual Pipe Stand Models | Available | Available | – | – | |
Planetary Cutting Unit (PCU)
- Suction blower for swarf removal
- Universal clamping system
- Self-centering design
- Range for all pipe range
| PM-PC-110PE | PM-PC-200PE | PM-PC-450PE | ||
| Pipe Range | mm | 16-110 | 63-200 | 110-450 |
| Line Speed (Max.) | Mtrs/Min. | 25 | 12 | 5 |
| Max. Pipe Thickness | mm | 20 | 28 | 60 |
Piple Tilting Unit
- Pneumatically operated
- Easy receiving of pipes
- However we also provide inline belling units
- Two limit switch actuation – one for pipe cutter feedback and other for tilting the pipe
Coiling Unit
- Two station coiler unit
- Suitable for pipe size up to 20-125 mm
- Motorized coiling stations
- Manual strapping and coil removal
- Manual traverse
